Test sistem

Test sistem :: Hardware
Platforme

Soyo P4I875P DRAGON 2 Black (4AA2R BIOS)

ASUS SK8N (1003 beta 2 BIOS)

MSI K8T Neo-FIS2R (1.1b BIOS)
Procesor(i)

Intel P4 Extreme Edition 3.2GHz @ 800MHz FSB
(HT uključen)

Intel P4C 3.2GHz @ 800MHz FSB (HT uključen)

Athlon 64 FX-51 2.2GHz (Socket940)

Athlon 64 3200+ 2.0GHz (Socket 754)
Memorija

2x 256MB Corsair XMS3500C2 (2-2-2-5)

2x 512MB Legacy registered DDR400 (Athlon 64 FX-51) (2.5-3-3-5)
Grafička
kartica

nVIDIA GF FX5900 Ultra 256MB
Driveri :: NVIDIA Detonator 45.23
Muzička kartica CL Audigy Player
Driveri :: Audigy EAX4 031031
Kontroler integrirani
Hard disk(ovi)

Seagate Barracuda IV 40GB 7200rpm
CD-ROM

Kenwood TrueX72

Testni sistem :: Software
OS

Windows XP Professional
Service Pack SP1
Chipset datoteke

Intel Chipset Driveri :: 5.02.1003

Intel Application Accelerator :: 2.3.0.2164

VIA 4-in-1 Driveri :: 4.49

nForce3 Driveri :: 3.13
DirectX verzija 9.0a
3DMark 2001SE build 330, sve default
UT2003 Demo dm-antalus demo, no sound, modificirane Hard OCP
skripte
Quake 3 Arena Retail, v1.32 sve default, demo four.dm_66
SiSoft Sandra v2003 MAX3! Standard
SuperPi v1.10, 1M test
PCMark 2002 sve default
ScienceMark v2.0 Beta
Aquamark 3 CPU test
SPECviewperf v7.1, 1152x864x32
3dMark 2003 build 330, sve default

P4 Extreme Edition usporedili smo sa "starim" P4C 3.2GHz te s AMD
Athlon 64 3200+ i Athlon 64 FX-51 procesorima.

Krenimo s testom performansi:

SiSoft Sandra Memory Test
Int
Athlon 64 FX-51
5657

P4EE 3200/800/400
4942

P4C 3200/800/400
4851

Athlon 64 3200+
3029


0 10 00 20 00 30 00 40 00 50 00 60
00

Float
Athlon 64 FX-51
5577

P4EE 3200/800/400
4949

P4C 3200/800/400
4859

Athlon 64 3200+
3028


0 10 00 20 00 30 00 40 00 50 00 60
00


U Sandri vidimo da veća cache memorija nema naročitog utjecaja na sirovi memorijski
bandwidth. Iz tog razloga, Athlon 64 FX i dalje ostaje nedostižan zahvaljujući
svom integriranom wide memorijskom kontroleru koji radi na taktu samog procesora.
