Asus H97-PRO Asus H97-PRO

Zajedno sa Z97 serijom ploča i ova je doživjela kozmetičke izmjene u dizajnu kutije, te svakako one bitnije u dizajnu same ploče. Na klasičnoj kutiji s poklopcem, nalaze se sve bitne informacije o proizvodu. Asus trenutno uz ovu ima još četiri H97 modela, od čega su dvije micro-ATX, jedna mini-ITX te jedna ATX. Model kojeg danas testiramo je najjači, a kao dio cijele serije Asus navodi veliku izdržljivost i kompatibilnost ovih ploča sa preko 7000 sati testiranja sa 1000 različitih proizvoda i peterostruku zaštitu koja im produžuje vijek trajanja.

Asus H97-PRO Asus H97-PRO

Ploča dolazi zaštićena u zasebnom kartonskom omotaču, te u antistatičkoj vrećici. S obzirom da je riječ o ploči koja spada u niži tržišni razred, bundle nije naročito bogat te se sastoji od četiri SATA 6Gbps kabela, I/O zaštite, medija s upravljačkim programima i aplikacijama, te kao i uvijek iscrpnih uputa za korisnike.

Asus H97-PRO Asus H97-PRO

Izgledom, ploča jako podsjeća na jače Z97 modele (Pro i Deluxe), a od njih je jedino uža za oko 2.7 cm (30.5 cm x 21.8 cm), te time stane u kraća kućišta.  PCH hladnjak je sličan onima na Z97 modelima, samo je mali tanji i uži unatoč činjenici kako H97, baš kao i Z97 disipira 4.1 W energije. H97 je u suštini vrlo sličan Z97 čipsetu uz manje mogućnosti  kombiniranja PCIe stazica za grafičke kartice (podržava samo jedan x16 PCIe 3.0 utor), a nedostaje mu podrška za Extreme Tuning Utility. No, ima pridodane Small Business Advantage i identity Protection tehnologije, zbog čega je pogodan za poslovnu upotrebu. Na VRM-u ove ploče se nalazi omanji aluminijski hladnjak koji svoj posao obavlja vrlo solidno i zagrijava se tek kada krenemo s overclockingom. Layout ploče je dobar, ništa ničemu neće smetati, a kompromis zbog nedostatka prostora je tek napravljen kod dva SATA utora koji su morali biti postavljeni vertikalno.

Specifikacije
Asus H97-PRO
Podržani
procesori 		Intel® Socket 1150 for the 5/New 4/4 Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors
Supports Intel 22 nm CPU
Supports Intel Turbo Boost Technology 2.0
Čipset Intel H97
Memorija 4 x DIMM, Max. 32GB, DDR3 1600/1333 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
Utori
za proširenja		 1 x PCIe 3.0/2.0 x16 (x16 mode, gray)
1 x PCIe 2.0 x16 (max at x4 mode, black)
2 x PCIe x1
3 x PCI
Multi-VGA
podrška		 Supports NVIDIA Quad-GPU SLI Technology
Supports AMD Quad-GPU GPU CrossFireX Technology
LAN Intel I218V, 1 x Gigabit LAN Controller(s), featuring Turbo LAN
Intel LAN- Dual interconnect between the Integrated LAN controller and Physical Layer (PHY)
Audio Realtek ALC892 8-Channel High Definition Audio CODEC featuring Crystal Sound 2
– Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
Audio Feature :
– Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
– Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
– Audio amplifier: Provides the highest-quality sound for headphone and speakers
– Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
– Unique de-pop circuit: Reduces start-up popping noise to audio outputs
Storage Intel H97 chipset :
1 x SATA Express port, compatible with 2 x SATA 6.0 Gb/s ports
1 x M.2 Socket 3, with M Key, type 2260/2280 storage devices support (both SATA & PCIE mode)
4 x SATA 6Gb/s port(s), gray
Support Raid 0, 1, 5, 10
Supports Intel Smart Response Technology, Intel® Rapid Start Technology, Intel Smart Connect Technology
USB Intel H97 chipset :
6 x USB 3.0/2.0 port(s) (4 at back panel, blue, 2 at mid-board)
Intel H97 chipset :
8 x USB 2.0/1.1 port(s) (2 at back panel, black, 6 at mid-board)
BIOS 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2,
CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified Log, F12 PrintScreen function, F3 Shortcut function, and ASUS DRAM SPD (Serial Presence Detect) memory information
Format ATX Form Factor ( 30.5 cm x 21.8 cm )
Interni I/O portovi 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)
3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
1 x SATA Express connector: black, compatible with 2 x SATA 6.0 Gb/s ports
1 x M.2 Socket 3 for M Key, type 2260/2280 devices
1 x TPM header
1 x COM port(s) connector(s)
4 x SATA 6Gb/s connector(s)
1 x CPU Fan connector(s) (1 x 4 -pin)
3 x Chassis Fan connector(s) (3 x 4 -pin)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s) (Q-Connector)
1 x MemOK! button(s)
1 x GPU Boost switch(es)
1 x Clear CMOS jumper(s)
Specijalne značajke ASUS 5X Protection :
– ASUS DIGI+ VRM – 6 Phase digital power design
– ASUS Enhanced DRAM Overcurrent Protection – Short circuit damage prevention
– ASUS ESD Guards – Enhanced ESD protection
– ASUS High-Quality 5K-Hour Solid Capacitors – 2.5x long lifespan with excellent durability
– ASUS Stainless Steel Back I/O – 3x more durable corrosion-resistant coating
ASUS EPU :
– EPU
ASUS Exclusive Features :
– GPU Boost
– MemOK!
– AI Suite 3
– Ai Charger
– Anti-Surge
– USB 3.0 Boost
– Disk Unlocker
– Turbo LAN
– Crystal Sound 2
Interactive HomeCloud
– Media Streamer
ASUS Quiet Thermal Solution :
– Stylish Fanless Design Heat-sink solution & MOS Heatsink
– ASUS Fan Xpert 3
ASUS EZ DIY :
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 2
– ASUS UEFI BIOS EZ Mode
– Push Notice
ASUS Q-Design :
– ASUS Q-Shield
– ASUS Q-Slot
– ASUS Q-Connector
